How Appium UIAutomator2 Server Works

技术标签: Appium

转自:https://testerhome.com/topics/9240



简单概括一下:

ps. 我们都知道appium只有在uiautomator2下可以实现对toast的识别,那是因为Google新增了AccessibilityService服务,重写该服务可以实现对Notification和Toast内容的捕捉

appium-uiautomator2-server



  • 通信模块使用了Netty Server,较之bootstrap使用的ServerSocket,Netty是一个高性能、异步驱动的NIO框架,占用内存少,性能更好。

运行原理

  • 客户端通过传递desired capabilities给appium node server来创建一个session, appium server根据automationName去启动对应的driver,默认是android-driver。
  • automationName设为UIAutomator2,appium会调用appium-uiautomator2-driver,同时将uiautomator2 server的两个apk安装到测试设备上
    1. appium-uiautomator2-server-vx.x.x.APK,执行handlers
    2. appium-uiautomator2-server-debug-androidTest.apk,只有一个test,用于启动server



  • AppiumServlet ,管理请求的路由,将driver发过来的请求转发给对应Handler.
  • Handler,调用UiAutomator V2去执行指定操作,操作的结果经AppiumResponse统一封装
  • AppiumResponse,操作结果返回给appium-uiautomator2-driver,再将结果返给客户端

来源:网络
